Emerson EC3-X33 Specification
| Attribute | Value | |
| Manufacturer | Emerson |  |
| Product Number | EC3-X33 | |
| Product Type | Superheat Controller | |
| Weight | 1.54 lbs | |
| Power supply | 24VAC ±10%; 50/60Hz; 1A | |
| Plug-in connector | Removable screw terminals wire size 12-20 AWG | |
| Grounding | 1/4 in spade earth connecto | |
| Protection class | IP20 | |
| Connection to ECD-002 | ECC-Nxx or CAT5 cable with RJ45 connectors | |
| Digital Inputs | 0/24VAC/DC for stop/start function | |
| NTC input | Emerson temperature sensor ECN-N60 | |
| 4-20 mA Analog input | Emerson PT4-07M / PT4-18M / PT4-30M | |
| Power consumption | 25VA max. including EX4 … EX8 |
Emerson EC3-X33 Details
Description
The EC3 is a stand-alone universal superheat controller for stable superheat control with stepper motor driven electronic control valves and is used for air conditioning, refrigeration and industrial applications such as chillers, industrial process cooling rooftops, heat pumps, package units, close controls, cold room, food process and air driers. The EC3-X33 requires the use of the ECD-002 display key pad unit for setting up the controller.
Key Feature
Evaporating Pressure Limitation (MOP): Manages maximum evaporating pressure to protect system integrity.
Superheat Alarms: Provides low and high superheat alarms for enhanced safety.
Sensor Monitoring: Monitors sensors and wiring, detecting failures for reliable operation.
Preparation for Start-up
Evacuate the Entire Refrigeration Circuit: Ensure the entire refrigeration circuit is evacuated before proceeding.
Warning: Emerson Electrical Control Valves EX4 to EX8 are delivered in a half-open position. Do not charge the system with refrigerant until the valve is fully closed.
Apply Supply Voltage: Connect 24V supply voltage to the EC3-X33 while keeping the digital input at 0V. This will drive the valve to its closed position.
If you want to more details，please contact me without hesitate.Email：sales@sparecenter.com
Graph of Emerson EC3-X33
 |
A: White wire B: Black wire C: Blue wire D: Brown wire E: Plug cable assembly EX5-Nxx for connection to EX4/EX5/EX6/EX7/EX8 F: Remote control panel, system controller G: Alarm relay, dry contact. Relay coil is not energized at Alarm or power off H: Digital input (0V/open = Stop; 24V/closed = Start) I: Transformer Class II, 24VAC secondary / 25VA J: Third party controller (can use the analog output signal from EC3) |
