KONTRON CP306-V Specification
| Feature | KONTRON CP306-V Description |
|---|---|
| Form Factor | 3U CompactPCI, PICMG 2.0 compliant |
| Board Role | System Master CPU |
| Processor | Intel® Celeron® M 1.3 GHz (Scalable up to Pentium® M 2.0 GHz) |
| Chipset | Intel® 855GME + ICH4 |
| Memory | Up to 1GB DDR-SDRAM (333 MHz) via 200-pin SO-DIMM |
| Graphics | Integrated Intel® Extreme Graphics 2, supports DVI-I / VGA |
| Ethernet | 1x 10/100 Mbps Fast Ethernet (Front panel RJ45) |
| USB | 2x USB 2.0 (Front panel) |
| Serial Ports | 1x RS232 (Front panel via 8HP version or onboard header) |
| Storage | 1x CompactFlash (Type I/II), onboard 2.5" HDD mounting (8HP) |
| Additional I/O | PS/2 Keyboard/Mouse port (Front panel) |
| Power Consumption | Approx. 13W - 22W (Depending on CPU/Memory configuration) |
| Mechanical Pitch | Available in 4HP (Single Slot) or 8HP (Double Slot) |
| Operating Temp | Standard: 0°C to +60°C (Extended range optional) |
| Ruggedization | High shock and vibration resistance for industrial use |
2
KONTRON CP306-V Details
KONTRON CP306-V Overview
The Kontron CP306-V is a professional-grade 3U CompactPCI System Master CPU board designed for cost-sensitive industrial applications. As a key member of Kontron’s Value Line, KONTRON CP306-V delivers a perfect balance between high-end industrial reliability and cost-efficiency. Built on the Intel® Celeron® M architecture, KONTRON CP306-V serves as the robust "brain" for modular embedded systems requiring long-term stability and high vibration resistance.
Key Technical Highlights
KONTRON CP306-V Industrial-Grade Processing:
Equipped with an Intel® Celeron® M 1.3 GHz processor and the Intel 855GME chipset. KONTRON 3U CompactPCI system master CPU is optimized for low power consumption and high heat dissipation efficiency, making it ideal for fanless or enclosed environments.KONTRON CP306-V System Mastery & Standards:
Fully compliant with the PICMG 2.0 standard, acting as the System Master.KONTRON CP306-V handles bus arbitration, clock distribution, and management of peripheral I/O cards across the cPCI backplane.KONTRON CP306-V Advanced Visuals:
Features the integrated Intel Extreme Graphics 2 engine. The front-panel DVI-I interface supports dual independent displays, providing crisp output for complex HMI (Human Machine Interface) tasks.KONTRON CP306-V Flexible Storage & I/O:
Available in 4HP (single slot) or 8HP (double slot) configurations. The 8HP version adds an onboard 2.5" SATA/IDE HDD mounting and a front-accessible CompactFlash slot for easy data logging and OS booting.KONTRON CP306-V Rugged Connectivity:
Includes essential industrial I/O: 1x Fast Ethernet (RJ45), 2x USB 2.0, and a legacy PS/2 port, ensuring compatibility with both modern and classic industrial peripherals.
Target Applications
KONTRON 3U CompactPCI system master CPU Industrial Automation: Core controller for factory floor automation and PLC-based logic management.
KONTRON 3U CompactPCI system master CPU Transportation & Rail: Integrated into signaling systems, trackside control units, and Passenger Information Systems (PIS).
KONTRON 3U CompactPCI system master CPU Energy & Power Plants: Reliable data processing for grid monitoring and renewable energy control cabinets.
KONTRON 3U CompactPCI system master CPU Medical Technology: Backend computing for diagnostic equipment and imaging control systems.
3
CP306-V KONTRON Images
CP306-V KONTRON
CP306-V KONTRON
CP306-V KONTRON
CP306-V KONTRON
4
CP306-V KONTRON FAQ
1. What is the primary role of the CP306-V in a CompactPCI chassis?
The CP306-V is specifically designed as a 3U CompactPCI System Master CPU.CP306-V KONTRON functions as the central controller of the system, responsible for bus arbitration, clock distribution, and managing communication with peripheral I/O cards via the PICMG 2.0 compliant backplane.
The CP306-V is specifically designed as a 3U CompactPCI System Master CPU.CP306-V KONTRON functions as the central controller of the system, responsible for bus arbitration, clock distribution, and managing communication with peripheral I/O cards via the PICMG 2.0 compliant backplane.
2. Which processor architecture powers the CP306-V "Value Line" board?
The CP306-V utilizes the Intel® Celeron® M processor (typically clocked at 1.3 GHz) paired with the Intel 855GME chipset. This configuration is the core of Kontron's "Value Line," engineered to provide a high price-to-performance ratio and low power consumption for cost-sensitive industrial projects.
The CP306-V utilizes the Intel® Celeron® M processor (typically clocked at 1.3 GHz) paired with the Intel 855GME chipset. This configuration is the core of Kontron's "Value Line," engineered to provide a high price-to-performance ratio and low power consumption for cost-sensitive industrial projects.
3. Does the CP306-V support dual-display outputs for HMI applications?
Yes, the CP306-V features the integrated Intel Extreme Graphics 2 engine. Through its front-panel DVI-I interface, CP306-V KONTRON can support dual independent displays (via a splitter cable or DVI-to-VGA adapter), making it suitable for complex medical imaging or industrial monitoring tasks.
Yes, the CP306-V features the integrated Intel Extreme Graphics 2 engine. Through its front-panel DVI-I interface, CP306-V KONTRON can support dual independent displays (via a splitter cable or DVI-to-VGA adapter), making it suitable for complex medical imaging or industrial monitoring tasks.
4. What are the mechanical differences between the 4HP and 8HP versions of the CP306-V?
The CP306-V(CP306-V KONTRON) is available in two widths: the 4HP version is a single-slot solution for space-constrained racks, while the 8HP version occupies two slots to provide additional expansion, such as an onboard mounting for a 2.5-inch HDD and a front-accessible CompactFlash slot.
The CP306-V(CP306-V KONTRON) is available in two widths: the 4HP version is a single-slot solution for space-constrained racks, while the 8HP version occupies two slots to provide additional expansion, such as an onboard mounting for a 2.5-inch HDD and a front-accessible CompactFlash slot.
5. Is the CP306-V(CP306-V KONTRON) suitable for deployment in high-vibration industrial environments?
Absolutely. The CP306-V is built with a ruggedized design and features a passive cooling (fanless) option.CP306-V KONTRON's robust construction is tested to withstand the significant shock and vibration levels typical of Industrial Automation and Railway Control systems.
Absolutely. The CP306-V is built with a ruggedized design and features a passive cooling (fanless) option.CP306-V KONTRON's robust construction is tested to withstand the significant shock and vibration levels typical of Industrial Automation and Railway Control systems.
6. Can the CP306-V(CP306-V KONTRON) be used as a drop-in replacement for legacy 3U cPCI systems?
Yes, because the CP306-V adheres strictly to the PICMG 2.0 standard and utilizes mature Intel architecture, CP306-V KONTRON is an ideal candidate for legacy system upgrades. It offers a stable, long-term available replacement for older 3U cPCI CPU boards without requiring a complete system redesign.
Yes, because the CP306-V adheres strictly to the PICMG 2.0 standard and utilizes mature Intel architecture, CP306-V KONTRON is an ideal candidate for legacy system upgrades. It offers a stable, long-term available replacement for older 3U cPCI CPU boards without requiring a complete system redesign.
