Product Specification
| Manufacturer | General Electric | IS215UCVEH2AF |
| Product no. | IS215UCVEH2AF | GE IS215UCVEH2AF |
| Product type | VME Board | General Electric IS215UCVEH2AF |
| Number of Channels | 6 | GE VME Board |
| Origin of Country | USA | GE PLC Module |
Product Details And Images
| Product Details | Product Images |
Description: The IS215UCVEH2AF is a VME board developed by GE for the Mark VI control system. This single-slot VME board features a 300 MHz Intel Celeron microprocessor and 32 MB of DRAM memory. It offers flexible storage options with either a 16 MB or 128 MB Compact Flash Module. The board includes a 128 KB L2 cache for improved data access speeds and an 8K battery-backed SRAM that functions as NVRAM, supporting essential controller functions within the system. Board Configuration and Connectivity: Interface Ports: The IS215UCVEH2AF features two RS-232C serial ports and an Ethernet port, along with connectors for external peripherals such as a keyboard, mouse, and monitor. On-board Components: Equipped with a high-speed processor, flash memory, and DRAM, the board efficiently handles processing tasks and stores essential system data. Data Acquisition: The board channels external data through the VCMI communications board, with options for process I/O (simplex) or voted I/O (TMR) depending on system configuration. Variants: The UCV VME controller card comes in various versions, including the UCVE board, which provides one to three PROFIBUS-DP masters for communication based on ISO/OSI model layers one and two. IS215UCVEH2AF General Electric VME Board.GE IS215UCVEH2AF.General Electric IS215UCVEH2AF. |  |
 | |
 |
If you want to more details，please contact me without hesitate.Email：sales@sparecenter.com
