FC-TSDO-04UNI HONEYWELL Safety Manager System Module

FAQ of HONEYWELL FC-TSDO-04UNI

1. What is the HONEYWELL FC-TSDO-04UNI?

It is a Safe Digital Output Field Termination Assembly (FTA). It serves as an interface connecting field devices to the digital output modules within the Honeywell Safety Manager system.

2.What does "Universal Output" mean for this module?

Universal Output" means that each of its 4 channels can be configured to support various types of loads and power requirements.

3.What kind of safety rating does it have?

As a "Safe" series component within Safety Manager, it is designed for use in Safety Instrumented Systems (SIS) and supports applications requiring high Safety Integrity Levels (SIL), adhering to standards like IEC 61508/IEC 61511.

Feature:

• Field Wiring: Provides robust screw terminals for secure and reliable connection of field device wiring.

• Connection to I/O Module: Connects to the Safety Manager's I/O module via a system cable (the specific cable type is defined by Honeywell).Output Type: Universal Output, meaning each channel can be configured to support various load types and power requirements, offering flexibility for different field device connections (e.g., typically supports different voltage ranges like 24 VDC, 48 VDC, 120 VAC, or varying current capabilities, depending on the specific configuration and connected output module).

•  Safety Rating: As a "Safe" series component, it is designed for use in Safety Instrumented Systems (SIS) and supports applications requiring high Safety Integrity Levels (SIL) as per IEC 61508/IEC 61511 standards.
