Product Specification
| Specification | Product Image | |
|---|---|---|
| Manufacturers | KEBA |  |
| Product No. | DO272/A | |
| Type | Digital Output Controller Module | |
| Equipment class | III in accordance with IEC 61131-2 | |
| Max. power consumption K Bus 24 V | 2.1 W | |
| Max. power consumption K Bus 5 V | 0.4 W | |
| Number of outputs | 14 | |
| Rated voltage | 24 V DC | |
| Operating temperature | +5 °C to +55 °C | |
| Storage temperature | -40 °C to 70 °C | |
| Relative humidity of air | 10 % to 95 % (non condensing) | |
| Processing time | 1 ms | |
| Rated current | 2 A at 50 % coincidence per group | |
| Max. inductive load | 1 J at max. 0.2 Hz | |
Product Details
Description:The DO272/A KEBA Digital Output Controller Module is designed for precise and reliable control of industrial digital outputs in automation systems. It features 14 outputs with a rated voltage of 24 V DC, providing 2 A per group at 50% simultaneous usage. The module ensures high performance with a processing time of 1 ms and galvanic isolation between the output groups for enhanced safety. It supports a wide operating temperature range of +5 °C to +55 °C and offers protection against short circuits. With a compact design and flexible connection options, this module is suitable for applications requiring reliable digital control in demanding environments.
Feature: High Output Capacity: 14 digital outputs, each capable of handling 2 A at 50% simultaneous load, making it ideal for controlling a wide range of industrial devices.Fast Processing Time: Provides a fast processing time of 1 ms, ensuring quick and precise output switching for time-sensitive applications.Galvanic Isolation: Features galvanic isolation between output groups, protecting the system from electrical faults and ensuring safe operation in harsh industrial environments.Wide Operating Temperature Range: Operates effectively within a temperature range of +5 °C to +55 °C, suitable for diverse industrial conditions.Compact Design: Designed with open terminals and a grid dimension of 5.08 mm, allowing for flexible integration into control systems and minimizing space requirements.
If you want to more details，please contact me without hesitate.Email：sales@sparecenter.com
