Specifications
| Size (Height x width xdepth) | 8.83”(22.44cm)x3.50”(8.89cm)x3.94”(10.00cm) |
| Weight | 4 lbs. (1.8 kg) |
| HeatDissipation | 9Wmaximum |
| Group to GroupIsolation | 300V |
| Powersupply voltage | 93-132 VAC @ 9W |
| Power supply dropout time | 10mSminimum |
| Voltagemeasurement Range | -25.0mV to +150mV |
| Accuracy (at 25C) | 8 Hz |
Product Features
ABB GE 6232BP10820 IC660EBA023 has six inputcircuits,in three isolated groups." 10V commonmode voltage (maximum) allowed between 2 points in a group. Each group has two thermocouple input circuits and two remote cold junction compensation inputs. Group to group isolation is 300 volts. Each input can interface to type J, K, T, E, B, R, S, and N (#14 AWG Nicrosilvs.Nisil) thermocouples. The block provides cold junction compensation for all thermocoupleinput. measurements. Each channel can be configured to use an internal sensor, an externalsensor, or a user-defined value for cold-junction compensation. An extemnal signal from a remote junction can be either a voltage (XJV) or a current (XJl) analog of temperature. The XJV input is scaled for 1.0mV per degree Celsius and theXJI input is scaled for 1.0uA per degree Kelvin. After compensation,the block linearizes eachthermocouple input measurement according to the NBS monograph for the type in use.Each input measurement can be adjusted up to " 100.0C or" 100.0F for greatest accuracy.The blocks perform the following diagnostics:Internal fault detection Open Wire detection Overrange and Underrange inputindication High and low input alarms An output is provided to drive a BusSwitching Module (versionIC660BSM021 only). |
Product Compatibility
These blocks are compatible with PCIM and QBlM modules.Hand-held Monitor IC660HHM501D, version 3.5 (or later) isrequired. For a Series 90™-70 PLC, the CPU must be rel. 2(IC697CPU731or771)or later. The bus controller must be rel.2 (1C697BEM731)or later. The programmingsoftware mustbe Logicmasterm™ 90-70 rel. 2.02 or later For a Series Six™ PLC, the CPU must be rev. 105 or later. For a Series Six Plus PLC, rev. 110 or later is required. The programming software must be Logicmaster™ 6 rel. 4.02 or later. For a Series Five PLC, the CPU must be rev. 3.0 or later.The Logicmaster 5 programming software must be rel. 2.01 or later. |
If you want to more details，please contact me without hesitate.Email：sales@sparecenter.com
Product Photos
Ⅰ
Ⅱ
Ⅲ
Ⅳ
ABB TRIO to GE Fanuc Conversion Table
| ABB TRIO Part # | GE Fanuc Part # | Description |
6200DP10800 6200FP10001 6200FP10004 6200FP10005 6202FP00075 6202FP00150 6203FP10800 6203FP10900 6230BP10710 6230BP10720 6230BP10730 6230BP10810 6230BP10820 6230BP10830 6231BP10810 6231BP10820 6231BP10830 6231BP10910 | IC660HHM501 IC660HHC005 IC660BPM500 IC660BCM501 IC660BLM506 IC660BLM508 IC660BSM021 IC660BSM120 IC660BBA100 IC660EBA100 IC660TSA100 IC660BBA020 IC660EBA020 IC660TSA020 IC660BBA024 IC660EBA024 IC660TBA024 IC660BBA10 | Hand-Held Monitor includes Cable and Battery Charger Hand-Held Monitor Cable Hand-Held Monitor Battery Pack Hand-Held Monitor Battery Charger Bus Terminator 150 Ohm Bus Terminator 75 Ohm Bus Switching Module 24/48Vdc Bus Switching Module 115Vac/125Vdc Block 115Vac Analog 4 Inputs / 2 Outputs Electronic Assembly for IC660BBA100 Terminal Assembly for IC660BBA100 Block 24/48Vdc Analog 4 Inputs / 2 Outputs Electronic Assembly for IC660BBA020 Terminal Assembly for IC660BBA020 Block 24/48Vdc Analog Current 4 Inputs / 2 Outputs Electronic Assembly for IC660BBA024 Terminal Assembly for IC660BBA024 Block 115Vac/125Vdc Analog Current Source 4 Inputs / 2 Outputs |
