Honeywell 10101-2-1（Honeywell Digital Input Module） Specification
| Number of Channels | 16 |
| Input Voltage | 24 VDC |
| Input Current | 2 mA per channel |
| Output Voltage | 24 VDC |
| Output Current | 50 mA per channel |
| Response Time | 25 ms |
| Operating Temperature | -40 to 70 °C |
| Storage Temperature | -40 to 85 °C |
| Humidity | 0 to 95% RH, non-condensing |
| Vibration | 5 g rms, 10 to 500 Hz |
| Shock | 15 g, 11 ms |
| Dimensions | 1.0" x 5.0" x 8.0" (2.5 cm x 12.7 cm x 20.3 cm) |
| Weight | 0 lbs 6.1 oz (0.2 kg) |
2
Honeywell 10101-2-1（Honeywell Digital Input Module） Graphs And Figures
 |
| Honeywell 10101-2-1 |
| 10101-2-1 Digital Input Module，10101-2-1 Input Module，Honeywell Digital Input Module |
3
Honeywell 10101-2-1（Honeywell Digital Input Module） Description
1
10101-2-1 Input Module Key Features
Fail-Safe Design:The Honeywell 10101-2-1 incorporates a "fail-safe" design. In a normally energized system, any component failure will result in a de-energized input signal to the processor, ensuring a safe state.
High Accuracy:With an accuracy of ±0.1%, the module is ideal for applications requiring precise measurements.
Wide Measurement Range:Supports DC voltage measurements from 0 to 100 V, making it suitable for a variety of applications.
2
10101-2-1 Input Module Description
The Honeywell FSC-10101/2/1 is a fail-safe digital input module that is designed for safety and shutdown applications on the TPS system's Universal Control Network (UCN).
10101-2-1 Input Module is a 16-channel module that operates on 24 VDC.
The module provides a dual redundant fault tolerant design to ensure that the system will remain operational even in the event of a single module failure.
3
10101-2-1 Input Module Application
Industrial Automation:The 10101-2-1 Input Module provides reliable signal processing and I/O control for automated production lines, assembly systems, and material handling equipment.
Process Control:Engineered for precision measurement and control in continuous process industries, this module delivers accurate data acquisition for parameters such as pressure, flow, and temperature.
If you want to more details about 10101-2-1 Digital Input Module，please contact me without hesitate.Email：sales@sparecenter.com
4
Honeywell 10101-2-1（Honeywell Digital Input Module） Images
10101-2-1 Digital Input Module
10101-2-1 Digital Input Module
10101-2-1 Digital Input Module
